AXEON Flow Meter with SS Valve 2-20 GPM 1" MNPT X 1" MNPT Panel Mount

Part #: 205106
Regular price List Price $261.51
Please Login / Sign Up

The 205106 AXEON Panel Mount Flow Meters have an easy–to–read scale which has been silk–screened onto an acrylic body. These flow meters offer durability, accuracy, and high quality.


Features:
  • Solid One Piece Injection Molded Acrylic Body
  • Stainless Steel Float and Internals
  • Permanent Screen Printed Scales
  • Dual Scale in GPM/LPM or GPH/LPH
  • Individually Packaged
  • 100% Tested for Accuracy


  • Flow Range (gpm / lpm): 2 - 20 / 10 - 70
  • Integrated 316L SS Valve: Yes
  • Inner Connection (in): 1/2" FNPT
  • Outer Connection (in): 1" MNPT
  • Body: Acrylic
  • O–Rings: Silastic
  • O-Rings: Viton (Needle Valves)
  • Connections: Polypropylene
  • Guide: 316L Stainless Steel
  • Float: 316L Stainless Steel
  • Maximum Pressure: 125 psi
  • Temperature Rating: 120°F
  • Accuracy: ± 5%
  • AXEON Part Number: 205106
